Yamaha Robotics SMT Section has announced automated programming capabilities in YSUP factory software that streamline program generation for all surface-mount processes, including dispensing, printing, placement, and inspection.

With the latest version of the YSUP-PG programming module, users can quickly get optimised programs without the need for producing test assemblies to verify correct settings. Working from standard data sources such as the PCB gerber file, assembly CAD data, and component libraries, YSUP-PG generates programs for each machine. With optimised settings and all necessary corrections automatically applied, program generation accelerates the beginning of production.

Yamaha’s YSUP factory automation tools present a unified framework and graphical environment for programming, optimising, and monitoring equipment in the 1 STOP SMART SOLUTION. Building the complete surface-mount line this way lets users choose from Yamaha’s portfolio of equipment designed from the ground up for easy interoperability and rich interactions that support quality assurance and traceability. Buyers can customise their line by selecting the desired machine type for each process and then choosing optional features such as the dispensing head, placement head, and inspection camera resolution.

Defining the future of the 1STOP SMART SOLUTION, the latest YR series dispensers, printers, mounters, and inspection systems share a common machine control system that ensures seamless and efficient integration and supports powerful features such as QA Options and Mobile Judgement. These help operators anticipate and solve production issues in real-time to avoid stoppages and maximise productivity.

In addition, the YR equipment generation shares an advanced chassis design that enhances rigidity and reliability. Thanks to this approach, the recently announced YRP10e entry-level screen printer achieves class-leading performance, 25% faster and with 40% greater printing accuracy than its predecessor. Similarly providing advanced stability for fast, accurate and repeatable component placement in YRM10 and YRM20 mounters, the same chassis is also featured in Yamaha’s YRi-V automatic optical inspection (AOI) systems. Here, the unwavering platform ensures pin-sharp image capture up to high scanning speeds, leading to short inspection times with high coverage and consistently high accuracy, ultimately delivering enhanced productivity.

Building on the foundation and interconnection established by sharing these underlying features, equipment in the 1 STOP SMART SOLUTION introduces features that simplify and accelerate assembly and inspection. Automated features including stencil loading and aperture cleaning in the YRP printers, nozzle maintenance, component checking, and pickup verification in YRM mounters ensure fast and error-free production of high-quality assemblies. The latest YRi-V 3D AOI systems with advanced lighting, optics, and image processing add refinements including automatic alignment checking to accelerate inspection of assemblies such as LED lighting and motor position sensors.

About Yamaha Robotics SMT Section

Yamaha Surface Mount Technology (SMT) Section, a subdivision of Yamaha Motor Robotics Business Unit in Yamaha Motor Corporation, produces a complete selection of equipment for high-speed inline electronic assembly. This 1 STOP SMART SOLUTION includes solder paste printers, component mounters, 3D solder paste inspection machines, 3D PCB inspection machines, dispensers, and management software.

Bringing the Yamaha way to electronics manufacturing, these systems prioritize intuitive operator interaction, efficient coordination between all inline processes, and modularity enabling users to meet the latest manufacturing demands. Group competencies in servo-motor control and image recognition for vision (camera) systems ensure extreme accuracy with high speed.

The current product line includes the latest YR equipment generation, with advanced automated features for programming, setup, and changeovers, and new YSUP management software with state-of-the-art graphics and built-in data analytics.

Combining design and engineering, manufacture, sales, and service competencies, Yamaha SMT Section ensures operational efficiency and easy access to support for customers and partners. With regional offices in Japan, China, Southeast Asia, Europe and North America, the company provides truly global presence.
